Description
Main Features
– HD 1080P camera powered by Ambarella ISP processor and high-quailty CMOS sensor, provides perfect HD picture and video
– The 2-aixs mechanical and 3-aixs electronical gimbal provides stable and smooth footage in any situation
– With lightweight design, the drone flies faster
– Wth quick-release propellers, fast and powerful propulsion with durable,well balanced design
– Flight time is up to 25mins with 11.1V 2000mAh lipo batter
– 1km range 5.8G real time transmission system
– With DIY port, you can explore your way to play with the drone, like driving a servo, lighting a led or fireworks
– Remote Controller is built-in LCD screen, DVR, and User Interface
– Headless Mode,no need to adjust the position of aircraft before flying
– One key to return function makes it easily to find the way home
Specifications
Remote Control
Screen resolution: 480 x 272
Screen size: 4.3inch
Frequency: 2.4 – 2.483GHz, 5.725 – 5.850 GHz ( 40CH )
Max R/C distance: about 1000m
Built-in Battery: 2950 mAh LiPo battery with about 2.5h working time
Voltage: 3.7V
Charge port type: micro USB
DVR: 720 x 480 video resolution
Gimbal
Controlled Rotation Scope: 0 – 90 degrees pitch angle
Stabilization: 2-aixs mechanical and 3-aixs electronical gimbal
HD 1080P Camera
Lens: FOV 80-degree
Aperture: f2.0
Focal Distance: 3.54 mm
Equivalent Focal Distance: 27mm
Sensor: 1/3.2 inch CMOS
ISO Range: 100 – 3200 for video, 100 – 1600 for picture
Shutter Speed: 4 – 1/8000s
Max Bitrate: 60Mbps
Max Photo Resolution: 8M 3264 x 2448
Video Resolution: 1920 x 1080 30fps / 1920 x 1080 25fps
File System: FAT32 / exFAT
Image Format: JPG
Video Format: MP4
DVR: 1920 x 1080 30fps / 1920 x 1080 25fps
Adapter
Rated Output: 14V 0.8A
Rated Input: 100 – 240V – 50 / 60Hz 0.3A
Rated Output Power: 11.2W
Balance Charger
Rated Output: 11.1V 0.8A
Rated Input: 14V 0.8A
Applicable Battery: 3S
Charging Limit Voltage: 12.75V
Rated Voltage: 11.1V
Rated Capacity: 2000mAh / 22.2Wh
Weight: about 162g
Propeller
Quick-release propeller
Length: 7.5 inch
Pitch: 3.6 inch
Brand: Xiaomi
Type: Quadcopter
Features: Camera
Functions: Camera,FPV,Up/down,Forward/backward,Turn left/right,One Key Automatic Return,Headless Mode,One Key Follow,GPS Altitude Hold,Continuous Shooting,Aerial Photography,G-sensor Mode
Size: Medium
Satellite System: GPS,GLONASS
Sensor: Barometer
Max Flying Height: 500m
Max Speed: 18m/s
Max Ascent Speed: 6m/s
Max Descent Speed: 5m/s
Material: Plastic,Electronic Components
Kit Types: RTF
Level: Advanced Level
Remote Control: 2.4GHz Wireless Remote Control
Channel: 4-Channels
Radio Mode: Mode 1 & Mode 2 (Left & Right-hand Throttle)
Detailed Control Distance: 1000m
Compatible with Additional Gimbal: Yes
Battery: 11.1V 2000mAh 3S LiPo Battery
Product weight: 0.5600 kg
Package weight: 1.2000 kg
Product size (L x W x H): 28.50 x 22.90 x 6.90 cm / 11.22 x 9.02 x 2.72 inches
Package size (L x W x H): 30.00 x 25.00 x 10.00 cm / 11.81 x 9.84 x 3.94 inches
Package Contents: 1 x RC Quadcopter ( Battery Included ), 1 x Transmitter ( Battery Included ), 1 x Gimbal, 1 x USB Cable, 6 x Propeller, 1 x Charging Cable, 1 x Balance Charger, 1 x English Manual
